SounDigital 800.5 EVO 6 - 4 Ohm
SD800.5-4 EVO6
5 Channel amplifier
Very small size
4 x 100W / 1 x 400W
4 Ohm model
Läs Mera
2 990,00 kr
Beskrivning
Teknisk information
Bruksanvisningar
It′s not just about audio.
It′s sensation, technology and emotion. IT′S EVO6.
This isn′t just another amplifier, it′s a leap in the evolution of car audio.
It redefines amplifier design. Every detail has been redesigned for excellence in audio quality, making your musical perception much more immersive.
Introducing the new 800.5 EVO6. With the help of AI we have achieved a miniaturization never seen before, these are the smallest amplifiers in the world, breaking power density records.
High efficiency that fits anywhere.
Join us on a journey into the future.
It′s sensation, technology and emotion. IT′S EVO6.
This isn′t just another amplifier, it′s a leap in the evolution of car audio.
It redefines amplifier design. Every detail has been redesigned for excellence in audio quality, making your musical perception much more immersive.
Introducing the new 800.5 EVO6. With the help of AI we have achieved a miniaturization never seen before, these are the smallest amplifiers in the world, breaking power density records.
High efficiency that fits anywhere.
Join us on a journey into the future.
Power @ 4Ω: 4 x 100W RMS
Power @ 8Ω: 4 x 66W RMS
SUBWOOFER: 4Ω: 1 x 400W
Bridge Power @ 8Ω: 2 X 200W RMS
SUBWOOFER: 8Ω: N/A
Frequency Response (-3dB): 80Hz ~ 25kHz
SUBWOOFER: 5Hz ~ 80Hz
Low Pass Filter (12dB/octave): 80Hz
High Pass Filter (12dB/octave): 80Hz
Operating Voltage: 9V ~ 16V
SNR: 103.88dB
SUBWOOFER: 102dB
Input Sensitivity (RCA): 0.2V ~ 2V
Current Draw (music): 39A
Current Draw (max.): 78.7A
Total Efficiency: 80%
Damping Factor (@100Hz nominal impedance): 200
Power Cable: 10mm² (7 AWG)
Speaker Cable: 1.5mm² (15 AWG) / 2.5mm² (13 AWG)
Recommended Fuse (music): 40A
Recommended Battery (minimum): 60Ah
Width: 6.01″ / 15,7 cm
Lenght: 4.52″ / 11,7 cm
Height: 2.07″ / 5,5 cm
Weight: 0.74 kg / 1.63 lb
Älä kytke vahvistinta alle nimelliskuorman!
Do not run your amp under rated impedance!.
Power @ 8Ω: 4 x 66W RMS
SUBWOOFER: 4Ω: 1 x 400W
Bridge Power @ 8Ω: 2 X 200W RMS
SUBWOOFER: 8Ω: N/A
Frequency Response (-3dB): 80Hz ~ 25kHz
SUBWOOFER: 5Hz ~ 80Hz
Low Pass Filter (12dB/octave): 80Hz
High Pass Filter (12dB/octave): 80Hz
Operating Voltage: 9V ~ 16V
SNR: 103.88dB
SUBWOOFER: 102dB
Input Sensitivity (RCA): 0.2V ~ 2V
Current Draw (music): 39A
Current Draw (max.): 78.7A
Total Efficiency: 80%
Damping Factor (@100Hz nominal impedance): 200
Power Cable: 10mm² (7 AWG)
Speaker Cable: 1.5mm² (15 AWG) / 2.5mm² (13 AWG)
Recommended Fuse (music): 40A
Recommended Battery (minimum): 60Ah
Width: 6.01″ / 15,7 cm
Lenght: 4.52″ / 11,7 cm
Height: 2.07″ / 5,5 cm
Weight: 0.74 kg / 1.63 lb
Älä kytke vahvistinta alle nimelliskuorman!
Do not run your amp under rated impedance!.
