Ground Zero ULTRA A-2
EAN: 4037072024968
GZ ULTRA A-2
Ultra-high-end 2-channel SQ amplifier
2x 200W (@ 4Ω)
2x 330W (@ 2Ω)
2x 450W (@ 1Ω)
Two-step BIAS selector
Läs Mera
59 990,00 kr
Beskrivning
Teknisk information
Bruksanvisningar
The results of three years of development, uncountable listening sessions, comparisons, tuning and testing led to the GZ ULTRA A-2, the most advanced analogue amplifier on the market uniting perfectly selected components reduced to the minimum of distractingly influencing aspects creating a masterpiece of an amplifier, matching our very own intention and everybody´s uncompromised expectations, worth to be called ultra-high-end.
Not a huge surprise but a great honour, the performance of the GZ ULTRA A-2 charmed the members of the EISA, a group of international car audio trade journalists, right from the very first listening sessions that much that there was any doubt about the decision to award this amplifier as
“BEST PRODUCT – IN-CAR HIGH-END COMPONENT”
Not a huge surprise but a great honour, the performance of the GZ ULTRA A-2 charmed the members of the EISA, a group of international car audio trade journalists, right from the very first listening sessions that much that there was any doubt about the decision to award this amplifier as
“BEST PRODUCT – IN-CAR HIGH-END COMPONENT”
Channels:
2
Output Power: (@ 4Ω)
2x 200 Watts RMS
Output Power: (@ 2Ω)
2x 330 Watts RMS
Output Power: (@ 1Ω)
2x 450 Watts RMS
Output Power (@ 2Ω) bridged
1200 Watts
Signal-to-Noise
120 dB
Frequency Response
10 Hz – 80 kHz
BIAS Setting
Signal-to-Noise ratio (SNR) 120 dB (@ 100 Watts A-weighted)
Overall Disortion (THD + N) 0.001%
Damping factor 1500
Input sensitivy: Switchable (1/2/4/8 V)
Idle current @ BIAS Low 2.7 A
Idle current @ BIAS High 4.2 A
Recommended loudspeaker wiring: 4.0mm2
Recommended power wiring: 25mm2 (x2)
Fuses (inside / pc-board mounted) 2x 50A (MINI ANL)*
(*Replace a defective fuse only by a new fuse with identical value)
Dimensions (W x L x H)
250 x 502 x 80 mm / 9.84 x 19.76 x 3.15″
2
Output Power: (@ 4Ω)
2x 200 Watts RMS
Output Power: (@ 2Ω)
2x 330 Watts RMS
Output Power: (@ 1Ω)
2x 450 Watts RMS
Output Power (@ 2Ω) bridged
1200 Watts
Signal-to-Noise
120 dB
Frequency Response
10 Hz – 80 kHz
BIAS Setting
Signal-to-Noise ratio (SNR) 120 dB (@ 100 Watts A-weighted)
Overall Disortion (THD + N) 0.001%
Damping factor 1500
Input sensitivy: Switchable (1/2/4/8 V)
Idle current @ BIAS Low 2.7 A
Idle current @ BIAS High 4.2 A
Recommended loudspeaker wiring: 4.0mm2
Recommended power wiring: 25mm2 (x2)
Fuses (inside / pc-board mounted) 2x 50A (MINI ANL)*
(*Replace a defective fuse only by a new fuse with identical value)
Dimensions (W x L x H)
250 x 502 x 80 mm / 9.84 x 19.76 x 3.15″
