SounDigital 8000.1 EVO5 1 Ohm
SD8000.1-1 EVO5
Mono amplifier
8000W
1 Ohm model
Excellent price / quality ratio!
Läs Mera
7 990,00 kr
Beskrivning
Teknisk information
The 8000.1 EVO 5 is a compact and modern amplifier that delivers 8000W RMS of power in 1 channel.
Incorporated with the innovative MCPCB board. Increasing your efficiency and ensuring much more consistent performance.
Incorporated with the innovative MCPCB board. Increasing your efficiency and ensuring much more consistent performance.
Compatible with SD-RLC Remote level control.
Power @ 4Ω: 1 X 3844 WRMS
Power @ 2Ω: 1 X 5360 WRMS
Power @ 1Ω: 1 X 8000 WRMS
Frequency Response (-3dB):
8Hz ~ 20kHz
Subsonic (12dB/oct):
8Hz ~ 80Hz
Low Pass filter (12dB/oct):
50Hz ~ 20kHz
Bass Boost:
0dB ~ 12dB @ 50Hz
Operating Voltage:
9V ~ 16V
SNR
@ 1Ω: 92dB
@ 2Ω: 85dB
Input Sensitivity (RCA):
0.2V ~ 2V
Input Sensitivity (High Level input):
1.3V ~ 15V
Current Draw (music):
381A
Current Draw (max.)
762A
Total Efficiency:
80%
Damping Factor (@100Hz nominal impedance)
10000
Power Cable:
70mm² (00 AWG)
Speaker Cable
2 x 10mm² (7 AWG)
Recommended Fuse (music):
2 x 200A
Recommended battery (minimum):
2 x 220Ah
Width:
7.1″ / 18 cm
Length:
12.2″ / 31 cm
Height:
2.5″ / 6.32 cm
Weight:
8.79 lb / 3.99 kg
Älä kytke vahvistinta alle nimelliskuorman!
Do not run your amp under rated impedance!.
Power @ 4Ω: 1 X 3844 WRMS
Power @ 2Ω: 1 X 5360 WRMS
Power @ 1Ω: 1 X 8000 WRMS
Frequency Response (-3dB):
8Hz ~ 20kHz
Subsonic (12dB/oct):
8Hz ~ 80Hz
Low Pass filter (12dB/oct):
50Hz ~ 20kHz
Bass Boost:
0dB ~ 12dB @ 50Hz
Operating Voltage:
9V ~ 16V
SNR
@ 1Ω: 92dB
@ 2Ω: 85dB
Input Sensitivity (RCA):
0.2V ~ 2V
Input Sensitivity (High Level input):
1.3V ~ 15V
Current Draw (music):
381A
Current Draw (max.)
762A
Total Efficiency:
80%
Damping Factor (@100Hz nominal impedance)
10000
Power Cable:
70mm² (00 AWG)
Speaker Cable
2 x 10mm² (7 AWG)
Recommended Fuse (music):
2 x 200A
Recommended battery (minimum):
2 x 220Ah
Width:
7.1″ / 18 cm
Length:
12.2″ / 31 cm
Height:
2.5″ / 6.32 cm
Weight:
8.79 lb / 3.99 kg
Älä kytke vahvistinta alle nimelliskuorman!
Do not run your amp under rated impedance!.
