SounDigital 3000.1 EVO 5 - 1 Ohm
EAN: 7898644525415
SD3000.1-1 EVO5
1-channel amplifier
3000W
1 Ohm model
Small size
Läs Mera
2 990,00 kr
Beskrivning
Teknisk information
The 3000.1EVO 5 is a compact, modern amplifier that delivers 3000W RMS of power distributed over 1 channel.
The amplifier features exclusive and patented technologies that make the sound experience cleaner and more faithful, in addition to ensuring better performance and efficiency for the most daring projects.
The amplifier features exclusive and patented technologies that make the sound experience cleaner and more faithful, in addition to ensuring better performance and efficiency for the most daring projects.
Power @ 1Ω: 1 X 3000W RMS
Power @ 2Ω: 1 X 1980W RMS
Power @ 4Ω: 1 X 1307W RMS
Frequency Response (-3dB):
5Hz ~ 25kHz
Low Pass Filter:
50Hz ~ 500Hz
subsonic:
5Hz ~ 30Hz
Bass Boost:
0dB ~ 12dB @ 50Hz
Operating Voltage:
8V – 16V
SNR:
92dB
Input Sensitivity:
0.2V ~ 2V
Current Draw (Music):
1Ω: 149A
2Ω: 139A
4Ω: 140A
Current Draw With Resistive Load:
1Ω: 298A
2Ω: 277A
4Ω: 280A
Total Efficiency:
1Ω: 80%
2Ω: 86%
4Ω: 85%
Damping Factor:
2000
Power Cable:
35mm² (2AWG)
Audio Output Cable:
1Ω: 2 x 4.0 mm² (11 AWG)
2Ω: 2 x 2.5 mm² (13 AWG)
4Ω: 2 x 1.5 mm² (15 AWG)
Recommended Fuse (Music):
150A
Recommended Battery:
150Ah
Width:
5.3 in / 13.6 cm
Length:
8.9 in / 22.8 cm
Height:
2.1 in / 5.48 cm
Weight:
1.75 Kg.
