SLUTSTEG OCH TILLBEHÖR Slutsteg 1-kanals Soundigital 12000.1 EVOX 2ohm

Soundigital 12000.1 EVOX 2ohm

EAN: 7898644527037
SD12000.1-2 EVOX

1-channel amplifier
12000W
2 Ohm model
When you want to play LOUD!

Läs Mera
14 900,00 kr
Vikt: 7.33 kg
I lager
Frågor? Kontakta ossinfo(at)audioimport.fi
Beskrivning
Teknisk information
The EVO X Line brings the latest technology in a compact design with the highest quality components. From a pioneering technology, SounDigital brought to car audio amplifiers something that hadn′t been explored yet. The thermal coupling through the RTGP system.

The exclusive RTGP system (Thermal Recovery for Power Generation) assures SounDigital products with both higher thermal efficiency and robustness with higher stability.
Compatible with SD-RLC Remote level control.

Power @ 12.6V @ 4Ω: 1 X 7920 WRMS
Power @ 12.6V @ 2Ω: 1 X 12000 WRMS
Power @ 12.6V @ 1Ω: N/A
Power @ 14.4V @ 4Ω: 1 X 8831 WRMS
Power @ 14.4V @ 2Ω: 1 X 13380 WRMS
Power @ 14.4V @ 1Ω: N/A
Operating Voltage: 8V – 16V
Current Draw (Music): 627 A
Current Draw (Max): 1253 A
Recommended Fuse (Music): 675 A
Total Efficiency: 76%
Damping Factor: 200
Frequency Response (-3dB): 5Hz – 500kHz
SNR: 76dB
Crossover HPF: 5Hz – 30Hz
Crossover LPF: 50Hz – 500Hz
THD + N (10% Rated Power): 0.1%
Product Dimensions: 20.8 x 8.8 x 2.8 in

Älä kytke vahvistinta alle nimelliskuorman!

Do not run your amp under rated impedance!.
