AMPIRE KV-DOBLO
KV-DOBLO
Reversing camera
IP68 waterproof
FIAT Doblo 2
OPEL Combo
Läs Mera
1 790,00 kr
Beskrivning
Teknisk information
Reversing camera for FIAT DOBLO 2 / OPEL Combo
Fastening screws accessible from the front
Image reproduction mirrored
Auxiliary lines: switched on at the factory (can be switched off by separating a cable loop)
Image sensor: 1/3 ″CMOS PC3089
Resolution 720x480 pixels
Viewing angle 150 ° diagonally
Viewing angle 120 ° horizontally
Image format: NTSC
580 lines resolution
IP68 waterproof
Minimum lighting 0.1 lux
Operating voltage: 9-16 volts DC
Power consumption: max. 150mA
Operating temperature: -20 ° to 70 ° C
Cable length: 10m + 1.5m on the camera
E approval E9-10R-05.1652
CE approval EN 55022: 2010 EN 61000-3-2: 2006 + A1: 2009 + A2: 2009 EN61000-3-3: 2008 EN 55024: 2010
FCC approval ANSI C63.4-2003
Installation note:
The camera is not suitable for continuous operation or monitoring. It must not be operated with an ignition (K15), as this could damage the camera through overheating.
