Ground Zero GZNW 15X-D2
GZNW 15X-D2
15″
SPL-subwoofer
3000W
FS (35.2 Hz)
XMAX 62mm!
Läs Mera
5 490,00 kr
Beskrivning
Teknisk information
Bruksanvisningar
The return of the legend, bigger than ever!
Combining the looks of the blue GZNW 12X with modern subwoofer technology and years of experience, Ground Zero creates even bigger long awaited successor.
Features:
- Long excursion subwoofer
- Klippel® optimized
- Aluminum cone & dust cap
- Massive blue aluminum cast basket
- 3” copper voice coil
- High-roll surround
- 4-layer polycotton spider
Combining the looks of the blue GZNW 12X with modern subwoofer technology and years of experience, Ground Zero creates even bigger long awaited successor.
Features:
- Long excursion subwoofer
- Klippel® optimized
- Aluminum cone & dust cap
- Massive blue aluminum cast basket
- 3” copper voice coil
- High-roll surround
- 4-layer polycotton spider
Voice coil diameter (mm / inch) 75 / 3”
Impedance (Ohm) 2 x 2
Re (Ohm) 4.02 (serial)
FS (Hz) 35.2
Qms 9.05
Qes 0.57
Qts 0.54
Le (mH) 2.73
Vas (Liter / cu.ft.) 28 / 0.99
MMS gr 513.65
Xmax (mm / inch) 62 / 2.44
SPL (1w/1m) 85
BL (Tesla – m) 28.29
Sd (cm²) 706.86
Power handling (Watts RMS/SPL) 2500 / 4000
Empfohlene Verstärkerleistung / Recommended
amplifier power
2000 – 3000 WRMS
@4 ohms (1 ohm)
Impedance (Ohm) 2 x 2
Re (Ohm) 4.02 (serial)
FS (Hz) 35.2
Qms 9.05
Qes 0.57
Qts 0.54
Le (mH) 2.73
Vas (Liter / cu.ft.) 28 / 0.99
MMS gr 513.65
Xmax (mm / inch) 62 / 2.44
SPL (1w/1m) 85
BL (Tesla – m) 28.29
Sd (cm²) 706.86
Power handling (Watts RMS/SPL) 2500 / 4000
Empfohlene Verstärkerleistung / Recommended
amplifier power
2000 – 3000 WRMS
@4 ohms (1 ohm)
