DD Audio VO-W12a-D4

EAN: 8500139386744
VOW12a-D4

12″
Subwoofer
3000W
3″ voice coil
2 x 4 Ohm

Läs Mera
BLACK WEEK SPOT PRODUCT
1 990,00 kr
Vikt: 14.70 kg
I lager
Frågor? Kontakta ossinfo(at)audioimport.fi
Beskrivning
Teknisk information
A new VO-W12a adds a new dimension to your car′s audio and makes it more vibrant and intense.The VO-W woofers are PA style, high output woofers designed for enthusiasts who want sound quality and high output. By combining design elements from pro audio and high-end car audio, DD has developed a new type of ultra efficient driver aimed at delivering high levels of clean output. The VO-W woofers feature performance refinements like large diameter voice coils, high-energy motors and cast frames. The low moving mass design coupled with tight motor tolerance produces ultra fast transients and high output able to keep up with any subwoofer system, or you can use them as stand alone PA drives. The VO-W Woofers will transform an ordinary system into a concert level crowd pleaser.
Speaker Size12″
Watts RMS500-1500
Watts Peak3000
Voice Coil Diameter - in3
Voice Coil ImpedanceDual 4 Ohm
Piston Diameter - in10.25
Fs - Hz39
Qms4.381
Qes0.439
Qts0.399
Vas - liters30.301
dBSPL88
Xmech - mm70
Xmax - mm8
Frame OD - in12.625
Frame OD w/Gasket - in12.75
Mounting Diameter - in11.125 (28,25cm)
Mounting Depth - in6.75 (17.14cm)
Motor Depth - in3 (7.62cm)
Motor Diameter - in7.87 (19,98cm)
Magnet Weight - oz160 (4,5kg)
Woofer Displacement - ft30.12
Sealed Enclosure - cu ft1.5-2.5 (42-70l)
Ported Enclosure - cu ft1.75-2.75 (49-78l)
